The 56L-200 200cc Youth ATV Full-Size (Burgundy) is a full-frame adult-size ATV designed for older youth and adult riders who need a stable, automatic quad with strong power and reliable braking. It features a 200cc single-cylinder, 4-stroke air-cooled engine that delivers solid torque for trail riding, property use, and recreational off-road driving.
With front and rear hydraulic disc brakes, large 23” front and 22” rear tires, and steel wheel hubs, this ATV offers dependable control and durability on dirt, gravel, and uneven terrain. The wide wheelbase and full-size dimensions provide improved balance and rider confidence.
This unit ships brand new, 70% assembled inside a metal crate, and is finished in Burgundy, with other colors available depending on stock.
Key Features
-
Full-size 200cc youth / adult ATV
-
Single-cylinder, 4-stroke air-cooled engine
-
Front & rear disc braking system
-
Large 23” front / 22” rear tires
-
Durable steel wheel hubs
-
Automatic operation (no clutch)
-
Wide stance for stability
-
Suitable for trails and recreational off-road use
Specifications & Technical Details
| Item | Details |
|---|---|
| Model | ATV-56L-200 |
| Year | 2021 |
| Engine Model | 1P63QML |
| Engine Type | 1-Cylinder, 4-Stroke, Air-Cooled |
| Displacement | 200 cc |
| Ignition | CDI |
| Battery | 12V / 9Ah |
| Max Power | 9.1 kW @ 7500 rpm |
| Max Torque | 10 N·m @ 6000 rpm |
| Front Brake | Disc |
| Rear Brake | Disc |
| Front Tire | 23 × 7-10 |
| Rear Tire | 22 × 10-10 |
| Wheel Hubs | Steel |
| Wheelbase | 1115 mm |
| Ground Clearance | 135 mm |
| Overall Dimensions | 1700 × 1040 × 1100 mm |
| Net Weight | 170 kg |
| Max Load | 150 kg |
| Wheel Pressure (F/R) | 100 / 100 kPa |
| Color | Burgundy (Black, Red, Blue also available) |
Usage & Rider Information
-
Off-road use only
-
Designed for older youth and adult riders
-
Full-size chassis for improved stability
-
Suitable for dirt trails, open land, and recreational riding
Assembly, Warranty & Delivery
This ATV is shipped brand new and 70% assembled inside a metal crate.
Final assembly, prep, and maintenance must be completed by a certified technician.
Warranty
-
30-day replacement parts only
-
Labor, mechanic services, and returns are not covered
Delivery Includes
-
Lift gate service
-
Residential delivery
-
Shipping insurance
-
Delivery appointment scheduling
