BLADE 600 LE.X EPS ATV 561cc
VALIANT AND LEGENDARY
BLADE 600 SE.X-EPS ATV is now all the rage since it released to the market.
The unique and confident design with modern LED-matrix headlights and Full-LED lighting, improved automatic transmission,
extended chassis, powerful engine, pleasant handling and excellent driving characteristics. Front radiator grille is removable for easy cleaning.
The whole new 600SE.X EPS will definitely drive all attentions on you!
TGB BLADE 600 SE.X-EPS ATV - watch on youtube
Engine Type 561 cc,Single Cylinder, SOHC
Bore X Stroke Ø 95 × 79.2 mm
Compression Ratio 10.2
Fuel System 42 mm Throttle Body / Programmed Fuel Injection
Max Power 44.8 HP / 6500 rpm
Max Torque 46.5 Nm / 5500 rpm
Drive System 4 × 4 Shaft Drive
Gear Selection L / H / N / R / P
Transmission V-Belt CVT Automatic
Engine Braking System Standard
Over Ride Button Standard
Front Suspension Dual A-arm
Rear Suspension Dual A-arm with Anti-roll Bar
Front/Rear Brake Hydraulic Disc with piston caliper and Hydraulic Foot Brake
Parking Brake Park In Transmission / Lockable Hand Lever
Front Tire AT 25 × 8 – 12 , 6 PLY
Rear Tire AT 25 × 10 – 12 , 6 PLY
Wheelbase (mm) 1290
Length/Width/Height (mm) 2155 X 1240 X 1280
Fuel Capacity 18 L
Electrical Outlet Connector 2 DC 12V 10A 120W
Instrumentation Digital instrument panel with odometer, speedmeter, Tripmeter, RPM, transmission position,
fuel gauge, Hi-Temp/Low-Battery lights, high beam light, EFI checking, differential indicator, 2WD/4WD indicator, EPS indicator
Color Mountain Grey Candy Black
$250 Extra for Camo Colors (If Available)
Brand New 70% assembled inside a metal crate. Certified Technician required for Assembly,Prepp, Basic maintenance and all tech issues.Warranty covers 30 days for replacement parts only. Labor, mechanic and Returns NOT Covered.
