The TGB Blade 600 SE.X-EPS ATV in Candy Black is built for riders who want strong mid-size ATV power combined with advanced handling and modern styling. This model stands out with its extended chassis, EPS (Electric Power Steering), and Full-LED lighting system, making it equally capable for trail riding, exploration, and utility use.
Powered by a 561cc fuel-injected single-cylinder engine, the Blade 600 SE.X-EPS delivers smooth torque and dependable performance across mixed terrain. The shaft-driven 4×4 system ensures consistent traction, while the CVT automatic transmission keeps operation simple and responsive. A removable front radiator grille allows easy cleaning after dusty or muddy rides, helping maintain cooling efficiency.
With dual A-arm suspension, a rear anti-roll bar, and EPS assistance, the ATV remains stable and easy to control even during longer rides or rough conditions. The Candy Black finish gives the vehicle a bold, premium appearance that fits its aggressive stance.
Key Features
-
561cc single-cylinder SOHC engine
-
Electric Power Steering (EPS)
-
Shaft-driven 4×4 drivetrain
-
CVT automatic transmission (L / H / N / R / P)
-
Engine braking system with override button
-
Dual A-arm suspension with rear anti-roll bar
-
Full-LED lighting with LED-matrix headlights
-
Removable front radiator grille for easy cleaning
-
Digital multifunction instrument panel
Technical Specifications
| Specification | Details |
|---|---|
| Model | TGB Blade 600 SE.X-EPS |
| Engine Type | 561cc Single Cylinder, SOHC |
| Ignition | ECU |
| Starter | Electric |
| Bore × Stroke | Ø 95 × 79.2 mm |
| Compression Ratio | 10.2 : 1 |
| Fuel System | 42 mm Throttle Body, Programmed Fuel Injection |
| Max Power | 44.8 HP @ 6500 RPM |
| Max Torque | 46.5 Nm @ 5500 RPM |
| Transmission | CVT Automatic (V-Belt) |
| Gear Selection | L / H / N / R / P |
| Drive System | Shaft Drive 4×4 |
| Engine Braking | Standard |
| Override Button | Standard |
| Front Suspension | Dual A-Arm |
| Rear Suspension | Dual A-Arm with Anti-Roll Bar |
| Front / Rear Brakes | Hydraulic Disc with Piston Calipers |
| Parking Brake | Transmission Park + Lockable Hand Lever |
| Front Tires | AT 25×8-12, 6-Ply |
| Rear Tires | AT 25×10-12, 6-Ply |
| Wheelbase | 1290 mm |
| Dimensions (L×W×H) | 2155 × 1240 × 1280 mm |
| Fuel Capacity | 18 Liters |
| Electrical Outlets | Dual DC 12V / 10A / 120W |
Instrumentation & Indicators
Digital display includes:
-
Speedometer
-
Odometer
-
Trip meter
-
RPM gauge
-
Transmission position indicator
-
Fuel gauge
-
High-temperature warning
-
Low-battery warning
-
High-beam indicator
-
EFI system check
-
Differential lock indicator
-
2WD / 4WD indicator
-
EPS status indicator
Color Options
-
Candy Black
-
Mountain Grey
-
Camo colors available for $250 extra (if available)
Assembly, Warranty & Pickup
-
Brand new, 70% assembled in a metal crate
-
Certified technician required for assembly, prep, and maintenance
-
30-day replacement parts warranty only
-
Labor, mechanic services, and returns not covered
-
Assembled units available for pickup only from retail store in Dallas, Texas
